Clip Double Profiles Roll Forming Machine

1. Core definition and use
Double profile clip rolling forming machine is an efficient metal plastic processing equipment, through continuous rolling process synchronously or alternately produce two different cross-section profiles of metal sheets (such as roof panels, wall panels, C/Z purlins, etc.). Widely used in construction, warehousing, manufacturing and other fields, especially suitable for mass customized metal component production.

2. Working principle and technical advantages
1. Double contour forming principle
● Two-roll system design: equipped with two sets of independently adjusted roller sets, through the PLC control system to switch the forming path of different profiles, to achieve a multi-purpose machine.
● Continuous rolling process: the metal strip undergoes a “compression-bending – shaping” cycle between multiple sets of rollers, and gradually forms a target cross-section with an accuracy of ±0.1mm.
2. Core components
● High precision roller: 45# steel plated with hard chromium, surface hardness of HV900 or more, to ensure wear resistance and forming accuracy.
● Automation control: Integrated 7 inch touch screen +PLC system, support length setting, speed adjustment (10-18m/min) and fault warning.

3. Key parameters
Parameter item Typical Value Remarks
Processing thickness 0.3-0.8mm can be customized to 1.2mm (special steel)
Molding speed 12-15m/min double contour alternating mode decreased by about 10%
Applicable materials Galvanized steel, aluminum sheet, color steel support PPGI/GI/AL multi-material
Drive power Main motor 7.5kW+ hydraulic station 3kW energy-saving servo motor is optional
Control accuracy length error ±1mm laser ranging + encoder dual calibration
Parameter item Typical Value Remarks
Processing thickness 0.3-0.8mm can be customized to 1.2mm (special steel)
Molding speed 0-15m/min double contour alternating mode decreased by about 10%
Applicable materials GI/AL color steel support PPGI/GI/AL multi-material
Drive power Main motor 7.5kW+ hydraulic station 4kW energy-saving servo motor is optional
Control accuracy length error ±1mm laser ranging + encoder dual calibration

4. Industry application and market trend
1. Main application scenarios
Construction field: Metal roof/wall system (such as IBR corrugated plate, locking plate), steel structure purlin production.
Cold chain storage: customized insulation board corrugated + planar double profile, improve the adhesion of the insulation layer.
Automobile manufacturing: door inner plate reinforcement and plane area composite forming.

2. Driven by market demand growth
Automation upgrade: Replace the traditional stamping process, reduce the die change time (efficiency increased by 40%).
Customized requirements: Support non-standard contour design (such as solar bracket C +U combination).
Environmental compliance: Low noise design (≤75dB) to adapt to urban factory environmental standards.

5. Key considerations for equipment selection
Capacity matching: Select the molding speed according to the annual output (such as 500,000 ㎡/ year need ≥12m/min models).
Material compatibility: Check whether special materials such as aluminum, magnesium, manganese, titanium and zinc are supported.
After-sales service: preferred to provide overseas commissioning, roller lifelong maintenance of the brand.
